9328900990 Rev L BE1-951 ASCII Command Interface 11-5
Settings (S) Command Descriptions
Reading All Settings
All user programmable settings can be listed using the S command. This read-only command is useful for
documenting relay status during installation. The settings retrieved by the S command can be saved to a
standard text file and sent to another relay to be configured with the same settings. This type of settings
transfer takes less than one minute.
S Command
Purpose: Read all relay setting parameters
Syntax: S
Example: S
The S command returns the values of relay setting parameters in the same form that they are
programmed. It can be used at the end of a programming session to make a record of the relay settings.
If saved in a file, the report can be sent to another BE1-951 that will use the same settings. Because the
report that is created is a set of commands, sending the report to a different relay re-programs that relay
with the settings contained in the S report.
Reading Specific Groups of Settings
While the S command is useful for reading all relay settings, several commands are available to read
specific groups of settings.
Note: In examples throughout this manual, relay responses are printed in Courier New typeface.
SA Command
Purpose: Read all alarm settings for Major and Minor alarms
Syntax: SA
Example: SA
SA Command Example:
Example 1. Read all alarm settings.
>SA
SA-BKR1=0,0; SA-BKR2=0,0; SA-BKR3=0,0
SA-DIP=0.00; SA-DIN=0.00; SA-DIQ=0.00
SA-DVAR=0.0,0.0
SA-DWATT=0.0,0.0
SA-24= 0
SA-LGC=0
SA-MAJ=25/30
SA-MIN=29
SA-RESET=0
SB Command
Purpose: Read all breaker settings
Syntax: SB
Example: SB
SB Command Example:
Example 1. Read all breaker settings.
>SB
SB-DUTY=0,0.000e+00,0
SB-LOGIC=/IN1
