SETTINGS
Settings for your application need to be entered and confirmed before placing the relay in service.
Register settings such as breaker operations and breaker duty can be entered to match the current state
of your system.
PREPARING THE RELAY FOR SERVICE
Basler microprocessor-based protection systems are similar in nature to a panel of electromechanical or
solid-state component relays. Both must be wired together with inputs and outputs, and have operating
settings applied. Logic settings determine which protection elements are electronically wired to the inputs
and outputs of the device. Operating settings determine the pickup thresholds and time delays.
The logic and operating settings should be tested by applying actual inputs and operating quantities and
verifying proper output response. For more details, refer to Section 13, Testing and Maintenance. All of
the following connections and functions should be verified during commissioning tests:
• Proper connection and sensing of current and voltage signals
• Input and output contact connections
• I/O sensing versus virtual sensing
• Settings validation
• Proper operation of equipment (main or auxiliary)
• Proper alarming (to SCADA) and/or targeting
Refer to Section 7, BESTlogic Programmable Logic, for information about customizing preprogrammed
logic and creating user-defined logic, and Section 8, Application, for information about the application of
preprogrammed logic schemes.
COMMUNICATIONS CONNECTIONS
The following paragraphs describe the communication connections for the BE1-951. Section 11, ASCII
Command Interface, provides information about using the relay communication interface and lists all
communication commands along with a description and the syntax for each command.
RS-232 Connectors
Front and rear panel RS-232 connectors are Data Communication Equipment (DCE) DB-9 female
connectors. Connector pin numbers, functions, names, and signal directions are shown in
Table 12-2.
RS-232 cable connection diagrams are provided in Figures 12-36 through 12-40. Optional Clear to Send
(CTS) and Request to Send (RTS) connections are required only if hardware handshaking is enabled.
Table 12-2. RS-232 Pinouts (COM 0 and COM 1)
Name Function Name Direction
1 Shield ---- N/A
2 Transmit Data (TXD) From relay
3 Receive Data (RXD) Into relay
4 N/C ---- N/A
5 Signal Ground (GND) N/A
6 N/C ---- N/A
7 N/C ---- N/A
8 N/C ---- N/A
9 N/C ---- N/A
