INTRODUCTION
This appendix lists all ASCII commands, command syntax, brief command descriptions, and any
corresponding HMI screens. Commands are organized by function in the following groups and tables:
• Miscellaneous (
Table B-1)
• Metering (
Table B-2)
• Control (
Table B-3)
• Report (
Table B-4)
• Setting (
Table B-5)
• Alarm (
Table B-6)
• General (
Table B-7)
• Breaker Monitoring (
Table B-8)
• Programmable Logic (
Table B-9)
• User Programmable Name (
Table B-10)
• Protection (
Table B-11)
• Global (
Table B-12)
• DNP (
Table B-13)
An entry of x in the HMI Screen column represents multiple entry possibilities such as 0, 1, 2, or 3 for
setting groups or 43, 143, 243, or 343 for virtual switches.
Table B-1. Miscellaneous Commands
ASCII Command Function HMI Screen
ACCESS[=<password>]
Read/Set access level in order to change
settings.
N/A
EXIT Exit programming mode. N/A
HELP <cmd> or H <cmd> Obtain help with command operation. N/A
Table B-2. Metering Commands
ASCII Command Function HMI Screen
M Read all metered values. N/A
M-FREQ Read metered frequency. 3.10
M-I[<phase>] Read metered current in primary unit. 3.5 - 3.7
M-PF Read metered three-phase power factor. 3.9
M-S
Read metered three-phase VA in primary
units.
3.9
M-V[<phase>] Read metered voltage in primary units. 3.1 - 3.3
M-VAR
Read metered three-phase vars in
primary units.
3.8, 3.8.1 -
3.8.3
M-3V0 Read calculated neutral voltage. 3.4
M-WATT or M-W
Read metered three-phase watts in
primary units.
3.8, 3.8.1 -
3.8.3
Table B-3. Control Commands
ASCII Command Function HMI Screen
CO-<control>[=<mode>] Control operation. N/A
CS-<control>[=<mode>] Control selection. N/A
CS/CO-x43 Control virtual switches. 2.1.1 - 2.1.4
CS/CO-101 Control breaker control switch. 2.2.1
CS/CO-GROUP Control group. 2.3.1
CS/CO-OUTn Control output n. 2.4.1
