B-2 BE1-951 Command Cross-Reference 9328900990 Rev L
Table B-4. Report Commands
ASCII Command Function HMI Screen
RA[=0] Report/Reset alarm information. 1.3
RA-LGC[=0] Report/Reset logic alarm information. N/A
RA-MAJ[=0] Report/Reset major alarm information. N/A
RA-MIN[=0] Report/Reset minor alarm information. N/A
RA-REL[=0] Report/Reset relay alarm information. N/A
RB Read breaker status. 1.5.7
RB-DUTY[<phase>[=%duty>] Read/Set breaker contact duty log. 4.3.2
RB-OPCNTR[=<#operations>] Read/Set breaker operation counter. 4.3.1
RD Report all demand data. N/A
RD-PI<p>[=0] Read/Reset peak demand current.
4.4.3.1 -
4.4.3.5
RD-PVAR[=0] Read/Reset peak demand vars.
4.4.3.8 (+)
4.4.3.9 (-)
RD-PWATT[=0] Read/Reset peak demand watts.
4.4.3.6 (+)
4.4.3.7 (-)
RD-TI[<p>] Report today’s demand current.
4.4.1.1 -
4.4.1.5
RD-TVAR Report today’s demand vars.
4.4.1.8 (+)
4.4.1.9 (-)
RD-TWATT Report today’s demand watts.
4.4.1.6 (+)
4.4.1.7 (-)
RD-YI[<p>] Report yesterday’s demand current.
4.4.2.1 -
4.4.2.5
RD-YVAR Report yesterday’s demand vars.
4.4.2.8 (+)
4.4.2.9 (-)
RD-YWATT Report yesterday’s demand watts.
4.4.2.6 (+)
4.4.2.7 (-)
RE Report all energy data. N/A
RE-KVARH[=0] Read/Reset three-phase varhours.
4.5.3 (+)
4.5.4 (-)
RE-KWH[=0] Read/Reset three-phase watthour.
4.5.1 (+)
4.5.2 (-)
RF[-n/NEW][=0/TRIG] Read/Reset fault report data. N/A
RG Report general information. N/A
RG-DATE[=<M/D/Y>] or RG-DATE[=<D-M-Y>] Read/Set date. 4.6
RG-STAT Report relay status. N/A
RG-TARG[=0] Report/Reset target status. 1.2
RG-TIME[=hr:mn:sc] or RG-TIME[=hr:mn<f>sc] Report/Set time. 4.6
RG-VER
Read program version, model number,
style number, and serial number.
4.7
RO-nA/B[#].CFG/DAT Read oscillographic fault report. N/A
RS[-n/Fn/ALM/IO/LGC/NEW][=0]
Read/Reset Sequence of Events Record
Data.
N/A
Table B-5. Setting Command
ASCII Command Function HMI Screen
S Read all relay setting parameters. N/A
