Basler BE1-951 - Alarm Setting Commands; General Setting Commands

9328900990 Rev L BE1-951 Command Cross-Reference B-3
Table B-6. Alarm Setting Commands
ASCII Command Function HMI Screen
SA Read all major and minor alarm setting. N/A
SA-BKR<n>[=<mode>,<alarm limit>] Read/Set breaker alarm settings. N/A
SA-DI<p>[=<alarm level>] Read/Set demand alarm settings. N/A
SA-DVAR[=<alarm level>,<alarm level>] Read/Set var demand alarm setting. N/A
SA-DWATT[=<alarm level>,<alarm level>] Read/Set watt demand alarm setting. N/A
SA-LGC[=<alarm num 1>[/<alarm num 2>]…
[<alarm num n>]]
Read/Set logic alarm setting mask. N/A
SA-MIN[=<alarm num 1>[/<alarm num 2>]…
[<alarm num n>]]
Read/Set minor alarm setting mask. N/A
SA-MAJ[=<alarm num 1>[/<alarm num 2>]…
[<alarm num n>]]
Read/Set major alarm setting mask. N/A
SA-RESET[=<rst alm logic>]
Read/Set programmable alarms reset
logic.
N/A
Table B-7. General Setting Commands
ASCII Command Function HMI Screen
SG Read all general settings. N/A
SG-CLK[=<date format(M/D)>,<time format(12/24)>] Read/Program time and date format. N/A
SG-COM<#>[=<baud>,A<addr>,P<pglen>,
R<reply ack>,X<XON ena>]
Read/Set serial communication protocol. 6.1.1 - 6.1.3
SG-CT<x>[=<CT ratio>] Read/Set Phase/Neutral CT ratio. 6.3.1 - 6.3.2
SG-DI<x>[=<interval>]
Read/Set P(IA/IB/IC/var/watt), N and Q
demand interval.
N/A
SG-DSP[P/N] Read analog signal dsp filter type. N/A
SG-FREQ[=<freq(Hz)>] Read/Enter power system frequency. 6.3.8
SG-HOLD<x>[=<1/0 hold ena>] Read/Program output hold operation. N/A
SG-ID[=<relayID>,<stationID>]
Read/Set relay ID and station ID used in
reports.
N/A
SG-IN<x>[=<Recognition Time>,<Debounce Time>] Read/Set input recognition/debounce. N/A
SG-LINE[=<Z1>,<A1>,<Z0>,<A0>,<line length>] Read/Set system line parameters. N/A
SG-LOG[=<interval>] Read/Set load profile interval. N/A
SG-NOM[=<nom volts>,<nom amps>] Read/Set nominal voltage and current. 6.3.7
SG-OSC[=<# records saved>]
Read/Set the number of oscillographic
fault records saved.
N/A
SG-PHROT[=<phase rotation>] Read/Set phase rotation setting. 6.3.9
SG-SCREEN<x>[=<default screen number>] Read/Set default screen(s). N/A
SG-SGCON[=<time>] Read/Set SGC output time. N/A
SG-TARG[=<x/x/…x>,<rst TARG logic>]
Report/Enable Target list and Reset
Target logic.
N/A
SG-TRIGGER<x>[=<TRIPtrigger>,<Putrigger>,
<LOGICtrigger>]
Read/Set trigger logic. N/A
SG-VTP[=<VT ratio>,<connection>,
<27/59 mode>,<51/27R mode>]
Read/Set VT ratio, connection, and 27/59
pickup mode.
6.3.3 - 6.3.4
SG-VTX[=<VT_ratio>,<connection>] Read/Set Aux. VT ratio and connection. 6.3.5 - 6.3.6
