B-4 BE1-951 Command Cross-Reference 9328900990 Rev L
Table B-8. Breaker Monitoring and Setting Commands
ASCII Command Function HMI Screen
SB Read all breaker settings. N/A
SB-DUTY[=<mode>,<DMAX>] Read/Set breaker contact duty. N/A
SB-LOGIC[=<breaker close logic>] Read/Set breaker contact logic. N/A
Table B-9. Programmable Logic Setting Commands
ASCII Command Function HMI Screen
SL[:<name>] Obtain setting logic information. N/A
SL-24[=<mode>,<BLK logic>] Read/Set logic for 24 function modules. N/A
SL-25[=<mode>,<BLK logic>] Read/Set logic for 25 function modules. N/A
SL-27[=<mode>,<BLK logic>] Read/Set logic for 27 function modules. N/A
SL-32[=<mode>,<BLK logic>] Read/Set logic for 32 function modules. N/A
SL-47[=<mode>,<BLK logic>] Read/Set logic for 47 function modules. N/A
SL-<x>50T<p>[=<mode>,<BLK logic>] Read/Set logic for 50 function modules. N/A
SL-<x>51<p>[=<mode>,<BLK logic>] Read/Set logic for 51 function modules. N/A
SL-<x>59<p>[=<mode>,<BLK logic>] Read/Set logic for 59 function modules. N/A
SL-<x>62[=<mode>,<INI logic>,<BLK logic>] Read/Set logic for 62 function modules. N/A
SL-79[={mode},{RI logic},{STATUS logic},{WAIT
logic},{LOCKOUT logic}]
Read/Set logic for 79 function. N/A
SL-<x>81[=<mode>,<BLK logic>] Read/Set logic for 81 function modules. N/A
SL-BF<x>[=<mode>,<INI logic>,<BLK logic>]
Read/Set logic for breaker failure function
modules.
N/A
SL-GROUP[=<mode>,<D0 logic>,<D1 logic>,<D2
logic>,<D3 logic>,<automatic>]
Read/Set logic for setting group module. N/A
SL-N[=<name>]
Read, set, or copy the name of the
custom logic.
N/A
SL-VO<x>[=<Boolean equation>] Read/Set output logic. N/A
Table B-10. User Programmable Name Setting Command
ASCII Command Function HMI Screen
SN[-<var>[=<name>,<TRUE label>,<FALSE label>]] Read/Set user programmable names. N/A
Table B-11. Protection Setting Commands
ASCII Command Function HMI Screen
S<g> Read all protection settings. N/A
S<g>-24[=<Pickup>,<Time Delay>,<Reset Time>]
Read/Set 24 pickup level, time delay, and
reset delay.
5.x.1.1
S<g>-25[=<volts>,<ang>,<slip>,<mode>]
Read/Set 25 delta volts, phase angle, slip
frequency, and mode.
5.x.2.1
S<g>-25VM[=<live volts>,<dead volts>,<time
dial>,<logic condition>]
Read/Set 25VM pickups, time delay, and
logic condition.
5.x.2.2 -
5.x.2.4
S<g>-27<p>[=<Pickup>,<Time Delay>]
Read/Set 27 pickup level, time delay, and
mode.
5.x.3.1 -
5.x.3.2
S<g>-27R[=<Pickup>,<mode>]
Read/Set (51)/27R control level and
operating mode.
5.x.7.5
S<g>-32[=<Pickup>,<Time Delay>,<Direction>]
Read/Set 32 pickup level, time delay, and
direction.
5.x.4.1
S<g>-47[=<Pickup>,<Time Delay>] Read/Set 47 pickup level and time delay. 5.x.5.1
