Basler BE1-951 User Manual

9328900990 Rev L BE1-951 Command Cross-Reference B-5
ASCII Command Function HMI Screen
S<g>-<x>50T<p>[=<Pickup>,<Time Delay>]
Read/Set 50T pickup level and time
delay.
5.x.6.1 -
5.x.6.6
S<g>-<x>51<p>[=<Pickup>,<Time Delay>,<Curve>]
Read/Set 51 pickup level, time delay, and
curve.
5.x.7.1 -
5.x.7.4
S<g>-<x>59<p>[=<Pickup>,<Time Delay>]
Read/Set 59 pickup level, time delay, and
mode.
5.x.8.1 -
5.x.8.3
S<g>-<x>62[=<T1>,<T2>] Read/Set 62 time delay.
5.x.9.1 -
5.x.9.2
S<g>-67N[=<Mode>,<Quantity>]
Read/Set 67 Neutral Polarizing Mode and
Quantities.
5.x.10.1 -
5.x.10.2
S<g>-79<x>[=<Time Delay>] Read/Set 79 time delay.
5.x.11.1 -
5.x.11.4
S<g>-79SCB[=<step list>]
Read/Set 79 Sequence Controlled Block
output.
5.x.11.5
S<g>-<x>81[=<Pickup>,<Time Delay>,<mode>]
Read/Set 81 pickup level, time delay, and
mode.
5.x.12.1 -
5.x 12.6
S<g>-81INH[=<Pickup>] Read/Set 81 undervoltage inhibit level. 5.x.12.7
SP-60FL[=<I_Blk>,<V_Blk>] Read/Set loss of potential pickup setting.
5.5.2.1 -
5.5.2.2
SP-BF[<time>[m/s/c]]
Read/Set the breaker failure timer
setting.
5.5.1.1
SP-CURVE[=<A>,<B>,<C>,<N>,<R>]
Read/Set the user programmable 51
curve parameters.
N/A
SP-GROUP<x>[=<switch time>,<switch level>,<return
time>,<return level>,<protection element>]
Read/Program auxiliary setting group 1 -
3 operation.
N/A
SP-79ZONE[=<Zone Pickup Logic>] Read/Set Zone Sequence Pickup Logic. N/A
Table B-12. Global Command
ASCII Command Function HMI Screen
GS-PW<t>[=<password>,<com ports(0/1/2)>] Read or change a password. N/A
Table B-13. DNP Setting Commands
ASCII Command Function HMI Screen
SDNP
Read all Distributed Network Protocol
(DNP) settings.
N/A
SDNP-AIDV[=<defVarObj30>,<defVarObj32>]
Read/Set default variation for Analog
Input static and/or Change Event logic.
N/A
SDNP-DB[=current dead band>,<voltage dead
band>,<power dead band>]
Read/Set Analog Input event dead band
for current, voltage, and power points.
N/A
SDNP-SFCNTR[=<scaling factor>]
Read/Set scaling factor for breaker
operations counter.
N/A
SDNP-SFIV[=<SF of P,N,Q elements>,<SF of Ground
Current>,<SF of Phase and Line Voltages>,<SF of
Auxiliary Voltages>]
Read/Set scaling factors for currents and
voltages.
N/A
SDNP-SFPE[=<power sec./pri.>,<power SF>,<energy
SF>]
Read/Set power type, scaling factor (SF)
for power and SF for energy.
N/A
SDNP-SFT[=<SF of time period>,<SF of time stamp
part 2>]
Read/Set scaling factors for time period
and part 2 of any time stamp.
N/A
