Figure 4-162
Step 3 Select Channel, and then click
Add
.
Step 4 Select the
Enable
check box.
Step 5 Click to draw queuing rule and area.
Step 6 Click under the
Parameters
column, and then select alarm type to
Queue
People No. Alarm
or
Queue Time Alarm
.
Step 7 Click under the
Trigger
column, and configure alarm linkages.
Table 4-49
Parameter Description
Period
Configure the period and in the set time range, the corresponding
configuration item will be linked to start the alarm.
Alarm Out
The alarm device (such as lights, sirens, etc.) is connected to the
alarm output port. When an alarm occurs, the NVR device transmits
the alarm information to the alarm device.
Latch
When the alarm ends, the alarm extended for a period of time. The
time range is from 0 seconds to 300 seconds.
Alarm Upload
Select the check box. When an alarm occurs, the NVR device uploads
an alarm signal to the network (including the alarm center).
● This function is for some series products only.
● You need to set the alarm center first. For details, see "1.11.13
Alarm Center".
Send Email
Select the check box. When an alarm occurs, the NVR device sends
an email to the set mailbox to notify the user.
You need to set the email first. For details, see "1.11.10 Email".
Record Channel
Select the check box and select the needed recording channel
(support multiple choices). When an alarm occurs, the NVR device
activates the channel for recording.
You need to enable intelligent recording and auto recording first. For
details, see"1.1.4.6 Schedule".
Copyright © NSS Sp. z o.o.
User‘s Manual 152
