225

connection by configuring PPPoE settings to give the Device a dynamic IP address in the WAN.

To use this function, firstly you need to obtain the user name and password from the Internet

Service Provider.

Step 1 Select

Main Menu

NETWORK

PPPoE

The

PPPoE

interface is displayed. See Figure 4-231.

Figure 4-231

Step 2 Enable the PPPoE function.

Step 3 In the

User Name

box and

Password

box, enter the user name and password

accordingly provided by the Internet Service Provider.

Step 4 Click

Apply

to complete the settings.

The system pops up a message to indicate the successfully saved. The IP address

appears on the PPPoE interface. You can use this IP address to access the Device.

When the PPPoE function is enabled, the IP address on the

TCP/IP

interface cannot

be modified.

1.11.8 DDNS

When the IP address of the Device changes frequently, the DDNS function can dynamically

refresh the correspondence between the domain on DNS and the IP address, ensuring you

access the Device by using the domain.

Background Information

Ensure the Device supports the DDNS Type and log in the website provided by the DDNS

service provider to register the information such as domain from PC located in the WAN.

After you have registered and logged in the DDNS website successfully, you can view the

information of all the connected devices under this user name.

Step 1 Select

Main Menu

NETWORK

DDNS

The

DDNS

interface is displayed. See Figure 4-232.

224

Manual cascade: You can use manual cascade when there are 2 IPCs in the network

at least.

Figure 4-229

Step 4 Click and select the channel to be added.

The following interface is displayed after successful adding. See Figure 4-230.

Figure 4-230

1.11.7 PPPoE

PPPoE is another way for the Device to access the network. You can establish network

224
