Parameter Description
WB Mode
You can set camera WB mode. It can affect the image whole hue
so that the image can accurately display the environment status.
Different cameras supports different WB modes such as auto,
manual ,natural light, outdoor and etc.
Day/Night Mode
Configure the color and black&white mode of the image. This
setting is not affected by the configuration files. The default setting
is Auto.
● Color: The camera outputs color image only.
● Auto: Depends on the camera, such as overall brightness and
whether there is an IR light, either color image or black&white
image is output.
● B/W: The camera outputs Black and white image only.
● Sensor: It is to set when there is peripheral connected IR light.
The Sensor item is for some non-IR device only.
Step 3 Click
Apply
.
1.2.5 Video Overlay
You can set values for overlay and private masking.
1.2.5.1 Overlay
You can add the information of time and channel in the live view interface.
Step 1 Select
Main Menu
>
CAMERA
>
Overlay
>
Overlay
.
Step 2 Configure parameters.
Table 4-14
Parameter Description
Channel Select a channel.
Time Title
Select
Time Title
, and the time tile will be displayed in live view
and playback.
Drag time title to the target place and click
Apply
.
Channel Title
Select
Channel Title
, and the channel tile will be displayed in
live view and playback.
Drag channel title to the target place and click
Apply
.
Custom Title
You can custom title to be overlaid on the screen. Click
Setting
to set the information such as font size, title content and text
alignment, and then click
OK
.
Default Set as device default configuration.
Copy to
Click
Copy to
to copy the settings to other channels.
Step 3 Click
Apply
.
Copyright © NSS Sp. z o.o.
User‘s Manual 52
