149
Parameter Description
Voice Prompts
Check the box and then select the corresponding audio file from the
dropdown list. System plays the audio file when the alarm occurs.
Refer to "1.17.1 File Management" to add audio file first.
Buzzer Select the check box to activate the buzzer when an alarm occurs.
Step 3 Click
Apply
to complete the setup.
1.7.2.7 People Counting
System adopts video image and graphics analysis technology. System can calculate the
entry/exit people amount in the specified zone on the video. It can generate an alarm when the
amount has exceeded the threshold.
1.7.2.7.1 People Counting
Step 1 Select
Main Menu
>
AI
>
Parameters
>
People Counting
>
People Counting
.
The
People Counting
interface is displayed. See Figure 4-161.
Figure 4-161
Step 2 Draw people counting rule.
1) Click to draw people counting rule.
2) Configure parameters.
Table 4-47
Parameter Description
Name Customize the rule name.
Duration
Set the minimum time that the object stays until the alarm is
triggered.
Copyright © NSS Sp. z o.o.
149 User‘s Manual
