Parameter Description
PTZ Activation
Select the check box and click Setting to select the channel and PTZ
action. When an alarm occurs, the NVR device associates the channel
to perform the corresponding PTZ action. For example, activate the
PTZ in channel one to turn to the preset point X.
● Tripwire alarm supports to activate PTZ preset point only.
● You need to set the corresponding PTZ actions first, see "1.4.4
Calling PTZ Functions".
Delay
At the end of the alarm, the recording extends for a period of time. The
time range is from 10 seconds to 300 seconds.
Tour
Select the check box and select the channel for tour. When an alarm
occurs, the local interface of the NVR device displays the selected
channel screen.
● You need to set the time interval and mode for tour first, see
"1.16.2 Tour".
● After the tour is over, the preview interface is restored to the screen
split mode before the tour.
Log
Select the check box, the NVR device records the alarm information in
the log when an alarm occurs.
Voice Prompts
Check the box and then select the corresponding audio file from the
dropdown list. System plays the audio file when the alarm occurs.
Refer to "1.17.1 File Management" to add audio file first.
Buzzer Select the check box to activate the buzzer when an alarm occurs.
Step 8 Click
Apply
.
1.7.2.8 Heat map
Heat map technology can monitor the active objects distribution status on the specified zone
during a period of time, and use the different colors to display on the heat map.
Step 1 Select
Main Menu
>
AI
>
Parameters
>
Heat Map
.
The
Heat Map
interface is displayed. See Figure 4-163.
Copyright © NSS Sp. z o.o.
153 User‘s Manual
