Figure 4-188
Step 3 Set
Alarm-in Port
channel number and then select the Enable check box to enable
the function.
Step 4 Configure parameters. See Table 4-56.
Table 4-56
Parameter Description
Alarm-in Port Select a channel to set alarm.
Enable Check the box to enable the function.
Alarm Name Enter an alarm name.
Device Type NO (normal open) or NC (normal close).
Schedule
Define a period during which the alarm is active. For details, see "1.8.5.1
Motion Detection".
Alarm-out Port
The alarm device (such as lights, sirens, etc.) is connected to the alarm
output port. When an alarm occurs, the NVR device transmits the alarm
information to the alarm device.
Post-Alarm
When the alarm ends, the alarm extended for a period of time. The time
range is from 0 seconds to 300 seconds.
Show Message Check box to enable a pop-up message in your local host PC.
Report Alarm
Select the check box. When an alarm occurs, the NVR device uploads
an alarm signal to the network (including the alarm center).
● This function is for some series products only.
● You need to set the alarm center first. For details, see "1.11.13
Alarm Center".
Copyright © NSS Sp. z o.o.
User‘s Manual 176
