Specifications A 2
ekrPro Com
60
web guide controller EDV No.: MD.191.01.05/1.6.x Chapter: A 2
with analog sensors Date: 23.11.2007 Page: 1/7
A 2 Specifications
A 2.1 ekrPro Com
60
controller (version XT)
Power supply 24V DC ± 5%
Power consumption 4W (without motor)
Input capacitance approx. 950µF
Controller inputs 2 x sensors, -9,75 V ...+9,75 V oder 0 V ...+9,75 V
12 bit selectable via software.
1 x sensor, -10,3 V to +10,3 V, 12 bit
1x EFE pot, -10,3 V to +10,3 V, 12 bit
1x pot return, -10,3 V to +10,3 V, 12 bit
1 x tacho, -9,0 V to + 9,0 V
1x blocking, input resistor 4.7 KΩ, operating points (<4 V (low)
and >8 V (high)), but can only be used against “+“ switched
sensors (pnp)
FVG inputs 1x blocking, no
metallic separation
2x reference switch, no metallic separation
input resistor 4.7 KΩ,
operating points (<4 V (low) and >8 V (high)),
but can only be used against “+“ switched sensors (pnp),
supply 24V DC
Digital inputs 12x digital inputs, no
metallic separation,
input resistor 4.7 KΩ,
operating points (<4 V (low) and >8 V (high)),
but can only be used against “+“ switched sensors (pnp),
supply 24V DC
Power supply outputs 2 x 24V (for CCD Pro camera)
Controller outputs Controller outputs -10.3V to -10 V, 12 bit 1x analog output
-10 V to +10 V, 2 mA
2x IR pulses
1x lamp supply 5 V, 1 A
Digital outputs 4 x digital outputs +24V, 1.0A per output, 1.5A
in total
No metallic separation.
Protected against feedback (positive voltage)
Controller output stage 1x DC motor 24V DC, max. 3 A, short circuit protected.
Select voltage, current or tachometer control (in preparation)
PWM 20 kHz
FVG output stage 1 x stepping motor, max. 1.5A; not
short circuit protected
CAN-bus 1x plug, 1x socket; no metallic separation
Screw connections /
plugs
Variable through exchangeable connection plate;
see Appendix D6
Protection class IP 54
