Signification of the messages
Report Significance
no Errors OK message output
Width err. min. Web width measurement: Web width has fallen below the lower error limit.
Width warn min. Web width measurement: Web width has fallen below the lower warning limit.
Width warn max. Web width measurement: Web width has exceeded upper warning limit.
Width err. max. Web width measurement: Web width has exceeded upper error limit.
W. warn nor err. min. Web width measurement: Web width has neither fallen below lower warning
limit nor lower error limit.
W. warn nor err. max. Web width measurement: Web width has neither exceeded upper warning
limit nor upper error limit.
Width valid Web width measurement: Valid value
Hyd. Lock Output oil blocking
Tear Off Output tear-off detection
Motor Locked Actuator is locked (the motor symbol appears in the display with a lock in it).
Current Err. The current for the selected drive has exceeded the permissible current.
Short Circ. Err. Short circuit
Mot. Temp. Err. Overtemperature
Amp. Dis. Err. Controller not released. 24 V signal on terminal 53 missing.
Limit Sw. Err. Actuator has reached a software limit switch.
Edge Search t/o Err. Sensor positioning device: Timeout for edge detection process
Norming t/o Err. Sensor positioning device: Timeout for sensor normalisation
Norming Err. Sensor positioning device: Error during sensor normalisation
Edge Search Err. Sensor positioning device: Error during edge detection
Retr. t/o Err. Sensor positioning device: Timeout during free-running process
Lock Err. Sensor positioning device: Motor output stage blocked
Width Meas. Err. Sensor positioning device: During guidance (automatic operation), a slide of
the sensor positioning device has driven into the
inner limit switch.
Width Adj. Err. Sensor positioning device: During guidance (automatic operation), a slide of
the sensor positioning device has driven into the
inner limit switch.
Low Volt Err. Collective error message
(Condition changes with a change of the error LED in the controller front plate)
opt. Logic Err. Error in the optional logic
opt. Logic Bool 1 Optional logic output 1 (Params 1)
opt. Logic Bool 2 Optional logic output 2 (Params 1)
opt. Logic Bool 3 Optional logic output 1 (Params 2)
opt. Logic Bool 4 Optional logic output 2 (Params 2)
