Commissioning B 3
ekrPro Com
60
web guide controller EDV No.: MD.191.01.05/1.6.x Chapter: B 3
with analog sensors Date: 23.11.2007 Page: 18/73
- Repositioning – repositioning of the material after certain
events
The current position of the material web is saved once an event
takes place (e.g. web tear). Once the event has been rectified, the
material is repositioned to this position. This functionality is only
effective once pre-positioning has been activated.
- Velocities – adjustment of positioning speeds
• at the first setting after switching on:
Retract velocity: 60 mm / s
Edge push velocity: 5 mm / s
Slow manual velocity: 1 mm / s
Fast manual velocity: 60 mm / s
Norming velocity: 60 mm / s
- Special – Special settings for driving the FVG slides
• at the first setting after switching on:
Mode after error: Man
Carry out setting according to point B 3.7.5.5, if the settings listed
above, for the sensor adjustment unit, do not corresponding to the
operating requirements.
