BST ekrPro Com60 User Manual

Commissioning B 3
ekrPro Com
60
web guide controller EDV No.: MD.191.01.05/1.6.x Chapter: B 3
with analog sensors Date: 23.11.2007 Page: 64/73
Terminal
Line Significance 85 84 83 82 81 80 79 78 77 76 75 74
25 Reset Lim.Sw. 2
(reset stop switch 2)
X
0 0
X X X X X X X X X
26 Reset Lim.Sw. 2
(reset stop switch 2)
X
1 1
X X X X X X X X X
27 Set Overtemp.
(over-temperature)
X
1 1
X X X X X X X X X
28 Reset Overtemp.
(reset over-temperature)
X
0 0
X X X X X X X X X
29 Keyb.Lock ON
(keyboard interlock on)
1
X X X X X X X X X X X
30 Keyb.Lock OFF
(keyboard interlock off)
0
X X X X X X X X X X X
31 -
60
Do Nothing
(reserved)
1 1 1 1 1 1 1 1 1 1 1 1
Alternative digital input allocation: see Dig. In Table 2:
Terminal
Line Significance 85 84 83 82 81 80 79 78 77 76 75 74
1 set Auto
(automatic mode)
X X X X X X X X X
1 0 0
2 set MAN
(manual mode)
X X X X X X X X X
0 0 1
3 set SC
(servo center position)
X X X X X X X X X
0 1 0
4 opmode clear
(defined zero state operating mode)
X X X X X X X X X
0 0 0
5 set Edge1
(edge 1)
X X X X X
0 0 0 1
X X X
6 set Edge2
(edge 2)
X X X X X
0 0 1 0
X X X
7 set Center1&2
(center 1/2)
X X X X X X
0 1 1
X X X
8 set Edge3
(edge 3)
X X X X X X
1 0 0
X X X
9 set Edge3 Inv. (inverse edge 3)
X X X X X X
1 0 1
X X X
10 guid.mode clear
(defined zero state guiding mode)
X X X X X X
0 0 0
X X X
11 Shifted Center OFF
X X X X X
0
X X X X X X
12 Reset Prepos. Center
(reset pre-positioning to centre)
X X X X X
1
X X X X X X
13 Shifted Center ON
X X X
X X
1
X X X X X X
14 Set Prepos. Center
(pre-positioning to centre)
X X X
X X
0
X X X X X X
15 set Center1&2
(center 1/2)
X X X
X X
1
X X X X X X
16 FVG left
X X X
0 1
X X X X X X X
17 FVG right
X X X
1 0
X X X X X X X
18 FVG stop
X X X
1 1
X X X X X X X
19 FVG stop
X X X
0 0
X X X X X X X
