Terminal diagrams / Service displays B 4
ekrPro Com
60
web guide controller EDV-No.: MD.191.01.05/1.6.x Appendix B 4
with analog sensors Date: 23.11.2007 Page: 4/9
B 4.2.5 Terminal strip X4; Sensor 3 / EFE / OZ3:
Remarks Terminal
X4
Function
15 +5V / 1A
16 GND (+5V)
17 +12V Output ±12V
18 GND
19 -12V Output -12V
20 Analog input 7
Sensor 3
21 Analog input 1
EFE1 / OZ3
B 4.2.6 Terminal strip X6; Power supplies:
Terminal
X6
Function Remarks
40 GND
41 +24V
B 4.2.7 Terminal strip X7; Actuator:
Plug Terminal
X7
Function Remarks
42 Actuator A
X60
43 Actuator B
B 4.2.8 Terminal strip X8; CAN connections:
Plug Terminal
X8
Signal Remarks
88 CAN_GND
89 CAN_L
90 CAN_SHLD
91 CAN_H
X100
X101
