Commissioning B 3
ekrPro Com
60
web guide controller EDV No.: MD.191.01.05/1.6.x Chapter: B 3
with analog sensors Date: 23.11.2007 Page: 14/73
B 3.5.6.1 Automatic material set-up
1. Press the F1-key.
2. Completely cover the sensor’s scanning window with the
material to be scanned for approx. 2 seconds.
3. Completely remove the material from the sensor scanning
window (no material over the sensor).
4. Press the F2-key.
This completes the material set-up for this sensor. Material set-up is
finished when the same procedure has been carried out for any
other sensors connected to the controller.
B 3.5.6.2 Manual material set-up
1. Completely cover the sensor’s scanning window with the
material to be scanned.
2. Press the F3-key.
3. Completely remove the material from the sensor scanning
window (no material over the sensor).
4. Press the F4-key
The sequence is arbitrary, i.e. the dark setting (steps 1 and 2) or the
bright setting (steps 3 and 4) can be made first.
For sensors TW54 and T62, you must use the special
Material-Setup – Sensor 3 (see Point C 2.3.4).
