Specifications A 2
ekrPro Com
60
web guide controller EDV No.: MD.191.01.05/1.6.x Chapter: A 2
with analog sensors Date: 23.11.2007 Page: 5/7
A 2.7 Line sensor T 62 D 1
Power supplies: from the controller
Lamp voltage: 5 V; 0.8 A
Sensing distance: 15 -30 mm
Measuring range: 3 -8 mm
Line widths: 0.5 -5 mm
Output voltage: 0 to ±10V
Protection class: IP 65
Ambient conditions: Temperature: 0 to a max. 50 °C
Humidity: 5% - 90%, no condensation
Weight: 1,100 g
Case dimensions: B= 67 mm
H = 105 mm
D = 128 mm
A 2.8 Reflected light
measuring light barrier R 42 D, etc.
R 42 D 12 R 42 D 16
Power supplies: +12V, 12 mA or
±12V, 15 mA or
±15V, 20 mA
Lamp voltage: 5V, 4W; from the controller for a maximum of
one sensor
Max. distance: 1 m 2 m
Measuring range
in front of front lens:
15 mm 40 mm
Diameter of light beam
in front of front lens:
25 mm 55 mm
Diameter of light beam
at half distance
40 mm 55 mm
Output voltage:
at: U
B
= +12 V
U
B
= ±12 V
U
B
= ±15 V
Corresponding to change in illumination:
light
dark
8.5V 2V
8.5V 0V
10.5V 0V
Protection class: IP 65
Ambient conditions: Temperature: 0° – 70°C
(temperature compensation
only up to 50°C
Weight: 1,000 g 1,200 g
