Specifications
A 2
ekrPro Com
60
web guide controller
EDV No.:
MD.1
91.01.05/1.6.x Chapter:
A
2
with analog sensors
Date:
23.11.2007
Page:
6/7
A 2.9
Fork light barrier
G 53 C2/5
Power supplies:
from the controller
Lamp voltage:
5V
Fork width:
29 mm
Measuring range:
± 3.5 mm
Diameter of light beam:
11 mm
Protection class:
IP 65
Ambient conditions:
Temperature:
-20 to a max. 60 °C
Humidity:
5% - 90%, no condensation
Weight: 400
g
Case dimensions:
B=
21 mm
H =
85 mm
D =
87 mm
15
17
