Controls B 2
ekrPro Com
60
web guide controller EDV No.: MD.191.01.05/1.6.x Chapter: B 2
with analog sensors Date: 23.11.2007 Page: 2/6
Key Function
Menu navigation:
Jump back by one level
In editing box:
Cancels the last entry
Select controller settings or controller gain
for change the settings
Saves the settings at the end of the set-up
functions
Activates special functions
(e.g. oscillation)
(not used at the present moment)
Menu selection
B 2.2 Navigating within the system
Use the arrow keys and the F1 – F4 function keys to navigate
within the system.
The different functions are explained in the following.
If incorrect entries are made, or if functions are active which, for
example, prevent entering of parameters (e.g. keyboard lock) the
appropriate message windows are shown on the display for
5 seconds
This gives the user information about which error is present in the
current case. The message can be deleted using the "OK" key.
