BST ekrPro Com60 - Connecting Plate

To Previous Page

Flange connection plate D 6

ekrPro Com

web guide controller EDV-No.: MD.191.01.05/1.6.x Appendix: D6

with analog sensors Date: 23.11.2007 Page: 1/1

Appendix D 6 Connecting plate

ekrPro Com

; XT version

X60

X50 X51

X65

X70

X71

X100

X101

Sensor positioning device

CAN Bus connection

External 24 VDC

Outputs 24 VDC

power supply

Analog sensors

Actuator (motorised/hydraulic)

Line / contrast sensor

Servo-center

component

Main Page
