Appendix D 5: System overview
EDV no.: MD.191.01.05/1.6.x Issued: 23.11.2007
Servo-center
component
Analog sensors
Hydraulic system
Line sensor/
Reflection sensor
Electronic remote
fine ad
j
ustment
Remote control
Actuator with
position feedback
Actuator without
position feedback
Power module
Sensor positioning device with and
without material width measurement
FVGPro module
FVG 2K.../FVG 2MK...
FVG 1K.../FVG 1MK...
EMS 3/..., EMS4/...
BST Bus System
ekrPro Com
60
ekrPro Key
6
0
System overview D5
EFE1
230 V
