BST ekrPro Com60 - Terminal Diagrams

Terminal diagrams / Service displays B 4
ekrPro Com
60
web guide controller EDV-No.: MD.191.01.05/1.6.x Appendix B 4
with analog sensors Date: 23.11.2007 Page: 2/9
B 4.2 Terminal diagrams
B 4.2.1 Overview
Terminal
strip
Function Remarks
X1 Analog sensor 1
X2 Analog sensor 2
X3 Analog sensor 3 SC encoder / Namur
X4 Analog sensor 4 EFE
X6 Power supply 24V DC Input
X 7 DC motor (controller)
X8 CAN
X10 Enable and reference switch (FVG)
X12 Stepping motor (FVG)
X14 Digital inputs
X15 Digital outputs
X16 Analog outputs ±10V and tacho
X17 Power supply (output 24V DC) for camera, etc.
X18 Power supply (output 24V DC) for camera, etc.
X19 Power supply (output 24V DC) for internal auxiliary module
X20 PLC I/O (option) PLC connection option
X40 JTAG / OCDS
X41 RS232 Bootstrap
X42 RS232_TTL Field-bus
X44 RS232_PLC PLC development
X45 Display / keyboard
X46 Micro-processor – parallel 8 bit bus for auxiliary module
