Terminal diagrams / Service displays B 4
ekrPro Com
60
web guide controller
EDV-No.: MD.191.01.05/1.6.x Appendix B 4
with analog sensors Date: 23.11.2007 Page: 6/9
B 4.2.11 Terminal strip X14; Digital inputs:
Terminal
X14
Function Remarks
72 GND
73 GND
GND for inputs 0 - 11
74 Input 0
75 Input 1
76 Input 2
77 Input 3
78 Input 4
79 Input 5
80 Input 6
81 Input 7
82 Input 8
83 Input 9
84 Input 10
85 Input 11
See truth table
(chapter B 3.7.5.9.3)
86 + 24V
87 + 24V
+24V output
max. 200mA
B 4.2.12 Terminal strip X15; Digital outputs:
Terminal
X15
Function Note Remarks
63 GND
64 OK Displayed via the H64 LED OK relay
65 Web width
too small
Displayed via the H65 LED The lower warning
and/or error limit
was undershot.
66 Web width
too big
Displayed via the H66 LED The upper warning
and/or error limit
was exceeded.
67 Oil blocking
(hydraulic)
Displayed via the H67 LED Hydraulic blocking
at low level
