Description A 1
ekrPro Com
60
web guide controller
EDV No.: MD.191.01.05/1.6.x Chapter: A 1
with analog sensors Date: 23.11.2007 Page: 1/5
The start-up, maintenance and installation
instructions described in this operating manual
must be strictly adhered to!
A 1 Description
The aim of the operating manual is to enable you to use the
guiding system rapidly by explaining the basic settings for initial
start-up (start-up menu) and the conventional functions for
operation. In addition, the complex functions will be described
using selected examples for setting certain parameters.
A 1.1 General information
This family of control systems includes:
• ekrPro Com
60
: Controller with keyboard
• ekrPro Key
60
: External control keyboard.
Devices in the controller family can be interconnected at different
levels into a system network via a CAN-Bus.
A 1.2 Utilisation
The ekrPro Com
60
is a microprocessor controlled web guiding
controller. Together with other BST components it may be used for:
• Web edge guiding (right or left)
• Web center guiding
• Guiding on continuous or interrupted printed lines
• Guiding on continuous or interrupted printed edges (still
being prepared)
• Web width measuring
The controller includes a separate control unit that can directly
control the sensor adjustment unit and it can be interconnected into
the system.
Any other utilisation must first be authorised by the manufacturer.
There are also standard PLC compatible inputs and outputs as well
as an OK-reporting system present.
A 1.3 Housing Versions
The control unit ekrPro Com
60
is available in two different housing
versions:
• ekrPro Com
60
XT: Mounting unit
(e.g. for wall mounting)
• ekrPro Key
60
Desk XT: Built-in unit
(e.g. for insertion in a
control console)
!
