ekrPro Com
60
web guide controller EDV No.: MD.191.01.05/1.6.x
with analog sensors Date: 23.11.2007 Page: 1/2
Contents
Section B
Commissioning
Symbols used in this manual
Table of contents
B 1 Installation B1-1
B 1.1 Installation site requirements B1-1
B 1.2 Installation ekrPro Com
60
(Mounting unit) B1-1
B 1.2.1 Securing hole diagram B1-1
B 1.2.2 Installation B1-1
B 1.3 Installation ekrPro Com
60
Desk (Built-in unit) B1-2
B 1.3.1 Installation dimensions B1-2
B 1.3.2 Cabling B1-2
B 1.3.3 Installation B1-3
B 1.4 Installation instructions for EMC-wiring B1-4
B 1.5 Installation contrast/line sensor B1-5
B 1.5.1 Sensor arrangement B1-5
B 1.5.2 Installation line sensor T 62 D 1 B1-6
B 1.5.3 Installation reflection sensor TW 54 C 5 B1-7
B 2 Display and operating controls B2-1
B 2.1 Control panel B2-1
B 2.2 Navigating within the system B2-2
B 2.2.1 Function keys (F-keys) B2-2
B 2.2.2 Arrow keys B2-5
B 2.2.3 Buttons B2-6
B 3 Commissioning B3-1
B 3.1 General information B3-1
B 3.2 Electrical connections B3-2
B 3.3 Commissioning with a CAN bus B3-3
B 3.3.1 Check unit address or set up if necessary B3-3
B 3.3.2 Terminator activation B3-5
B 3.4 Adjust password B3-7
B 3.5 Commissioning standard system B3-9
B 3.5.1 Select standard system B3-9
B 3.5.2 Carry out master setup B3-10
B 3.5.3 Setting the actuator guiding direction B3-11
B 3.5.4 Setting the actuator path limits B3-11
B 3.5.5 Servo centre position and amplification for the B3-12
“SC” operating mode
B 3.5.6 Carry out material setup B3-13
B 3.5.6.1 Automatic material set-up B3-14
B 3.5.6.2 Manual material set-up B3-14
B 3.5.7 FVG - Sensor positioning device B3-15
B 3.5.8 Additional Functions B3-19
B 3.5.8.1 Tear Off Detection B3-19
B 3.5.8.1 Oscillation B3-23
B 3.6 Save settings B3-25
