Instructions for use Primus Infinity Empowered SW 4.5n 123
Operation
Reusable absorber
z Press the Standby key and confirm via the
rotary knob.
1 Slide the writing table (A) inwards.
2 Press the release button on the ventilator mod-
ule and pull the module out (B).
3 Turn the absorber counterclockwise (C) and
pull it down and off.
4 Empty out the used soda lime and dispose of in
accordance with the instructions for use of the
soda lime.
5 Fill the absorber to the upper mark with fresh
soda lime.
6 Fit the absorber into the breathing system from
below and turn it clockwise as far as it will go.
7 Slide the ventilator drawer in until it clicks into
place.
8 Pull the writing table out.
9 Reset the soda lime change log to current date
by pressing the soft key soda lime changed *,
see page 88.
Leak test
026027
A
B
C
* Only without configured CLIC absorber.
WARNING
Risk of patient injury
The system will be pressurized during the leak
test.
To prevent patient injury, do not perform the
leak test with a patient connected to the an-
esthesia machine.
WARNING
Risk of misleading measured values
Changing the breathing hoses, vaporizer, or
soda lime can modify the calculated leak and
compliance values of the anesthesia machine
and influence the therapy settings.
Carry out a leak test after the breathing hoses,
vaporizers, or soda lime has been replaced.
WARNING
Risk of incorrect volume application
If Infinity ID breathing hoses are used, the
compliance of the ID breathing hoses can be
transferred from the breathing hoses to the
anesthesia machine. Unlike the usual case in
which leak and compliance values are derived
from the system or leak test, exact determined
values will not be available.
Pay special attention to compliance and leak
values during operation.
