Dräger Primus Infinity Empowered - Setting the Vapor

Operation
98
Instructions for use Primus Infinity Empowered SW 4.5n
Setting the Vapor
The Vapor 2000 is shown and described here.
For the Dräger Interlock 2 System:
1 Lock the unused vaporizer = slide lever (A)
completely towards the unused Vapor (exam-
ple: left-hand Vapor locked)
If the handwheel is set to T:
2 Press 0 key (B), engage handwheel at 0. Wait
5 seconds for pressure to equalize.
3 Press 0 key and turn handwheel (C) counter-
clockwise to set the required anesthetic gas
concentration.
030
00
A
B
C
