Cleaning, disinfection and sterilization
230
Instructions for use Primus Infinity Empowered SW 4.5n
3 Tighten the knurled nut by hand.
4 Insert the ventilator diaphragm (C) so that the
Dräger legend is visible from above.
5 Hang the breathing system (D) into the ventila-
tor module.
6 Tighten the sealing screws (E) on the ventilator
cover using the key supplied.
Filling and fitting the absorber
The disposable absorber Drägersorb CLIC or a re-
usable absorber can be used.
Disposable absorber Drägersorb CLIC
The appropriate adapter must be installed by
trained personnel, e.g. DrägerService.
To click the absorber into place:
080079
C
D
051
NOTE
The disposable absorber must be clicked into
place before Primus Infinity Empowered is
switched on. This ensures that the absorber is in-
cluded in the leak and compliance test of the ma-
chine.
E
E
E
