Cleaning, disinfection and sterilization
222
Instructions for use Primus Infinity Empowered SW 4.5n
1 Remove the scavenging hose (A) from the AGS
system on the back of Primus Infinity
Empowered.
2 Remove the gray transfer hose (B).
3 Remove the anesthetic gas scavenging system
(C).
4 Prepare the individual parts for reprocessing in
a cleaning and disinfecting machine (washing
machine).
Flow tubes must not be placed in the washer!
5 Remove the container for buffer volume.
6 Unscrew the union nut (D).
7 Unscrew the flow tube (E).
8 Unscrew the union nut and remove the particle
filter (F).
The particle filter may be disposed of with ordi-
nary domestic waste after being sealed, see
"Maintenance" on page 237.
Note the instructions for use of the anesthetic gas
scavenging system AGS.
Removing the secretion aspiration
system (optional)
1 Remove the suction hose (A) and vacuum hose
(B) leading to the endotracheal aspiration sys-
tem.
2 Grip the silicone sleeve (C) of the bottle cap
(see details below) and pull it off.
3 Remove the secretion collecting bottle (D) and
rinsing bottle from the holder and empty them.
Note the hygiene regulations of the hospital.
Both secretion collecting bottles may contain in-
fectious secretions.
4 Remove the filter (E) at the bottom of the en-
dotracheal aspiration system.
(See "Maintenance" on page 237.)
055
D
E
F
056
NOTE
Always wear gloves when emptying the bottles.
A
C
DD
E
B
