Instructions for use Primus Infinity Empowered SW 4.5n 233
Cleaning, disinfection and sterilization
Inserting the ventilator module
1 Slowly push in the ventilator module (A) until it
engages.
2 Check to make sure no hoses or other parts are
caught when closing the drawer.
3 Pull the writing table (B) out.
Connecting the patient system
1 Fit the microbial filters (optional) on the inspira-
tory and/or expiratory port of the breathing sys-
tem until they audibly engage.
2 Connect the various parts of the breathing cir-
cuit (breathing hoses, Y-piece, connector, and
optional Y-piece filter) and hang the breathing
bag on the hook.
See "Connecting the patient system"
on page 63.
061
A
B
062
WARNING
Risk of burns
Conductive breathing hoses or face masks
may cause burns during HF surgery.
Do not use these types of hoses and masks in
combination with HF surgery.
