Cleaning, disinfection and sterilization
220
Instructions for use Primus Infinity Empowered SW 4.5n
2 Pull the breathing system up (B) and out by the
handle.
Removing the ventilator diaphragm
z Remove the upper diaphragm (A) and prepare
it for conditioning in a cleaning and disinfecting
machine.
Removing the flow sensors
1 Unscrew the inspiratory and expiratory ports
(A).
2 Remove the flow sensors (B).
052053
B
A
NOTE
If the ventilator diaphragm is reprocessed to-
gether with light-colored, transparent silicone
components, discoloration of these silicone com-
ponents may occur.
Do not reprocess the specified components to-
gether.
072
CAUTION
Risk of flow measurement failure
Disinfecting or cleaning the flow sensors by ma-
chine will damage them and cause the flow meas-
urement to fail.
Disinfect and clean the flow sensor as described
in the instructions for use of the Spirolog and
SpiroLife flow sensors.
AB
