Cleaning, disinfection and sterilization
218
Instructions for use Primus Infinity Empowered SW 4.5n
On the sleeve of the microbial filter:
1 Pull the filter off the nozzle.
2 Prepare the microbial filter for conditioning ac-
cording to the corresponding instructions for
use.
Removing the ventilator module
1 Slide the writing table (A) inwards.
2 Press the release button on the ventilator mod-
ule (B) and pull the module out.
Removing the flexible arm and breathing
bag
1 Take the breathing bag off the arm.
2 Unscrew the knurled screws (A) on the socket
of the arm.
3 Disconnect the arm from the breathing system.
Removing the absorber
The disposable absorber Drägersorb CLIC or a re-
usable absorber can be used.
Disposable absorber Drägersorb CLIC
1 Press the button (A); the mounting swings
open.
2 Slide the disposable absorber off the mounting
(B).
Note the Drägersorb CLIC instructions for use.
048016
B
A
A
092
A
B
