Instructions for use Primus Infinity Empowered SW 4.5n 55
Assembly and preparation
Accessory weight limits
The following figures specify the maximum safe
weight limits for accessories mounted to the Primus
Infinity Empowered.
Floor unit
Left side Top, front and rear of device Right side
The maximum permissi-
ble weight of accesso-
ries is 25 kg (55 lbs).
The maximum permissible weight of accessories on
the top cover of the device is 20 kg (44 lbs).
The maximum per-
missible weight of ac-
cessories is 25 kg
(55 lbs).
The maximum load on
the pull-out writing ta-
ble is 10 kg (22 lbs).
A maximum load of
15 kg (33 lbs) may be
applied with a clearance
of max. 40 cm (16 in) in
the upper position on
the lateral mounting rail.
The maximum load on
the lateral standard
rail is 5 kg (11 lbs).
A maximum load of
15 kg (33 lbs) may be
applied with a clear-
ance of max. 40 cm
(16 in) in the upper
position on the lateral
mounting rail.
The maximum load on
the drawer is 3 kg
(6.6 lbs).
The remaining weight
must be applied at a dis-
tance of 10 cm (4 in)
max.
The remaining weight
must be applied at a
distance of 10 cm
(4 in) max.
A maximum weight of 35 kg (77 lbs) may be applied to
the rear of the device (gas cylinders, holders and ac-
cessories).
