Assembly and preparation
54
Instructions for use Primus Infinity Empowered SW 4.5n
To increase tipping stability:
z Remove all monitors and devices from the
upper storage area.
z Dismantle any additional mounted devices
on swivel arms or on the upper side of the
device (e.g., patient monitoring, data man-
agement systems, syringe pumps, etc.).
z Remove vaporizers and gas cylinders.
z Clear the writing table and push it inwards
completely.
z Position the optional flexible arm for the
breathing bag close to the device.
z Push in the ventilator module and drawers.
z To transport the ceiling unit, pull out the
base of the ceiling unit and tighten it with the
knurled screw before lowering it to the floor.
NOTE
Risk of injury
To avoid tipping over the ceiling unit, pull out the
base before lowering it to the floor.
Push the base into the anesthesia machine when
mounted to the wall or ceiling supply unit.
CAUTION
Risk of physical injury
To avoid physical injury, e.g. pinching, pay special
attention to edges, moving parts and corners
when working with drawers, the ventilator module,
doors, the writing tray and/or swivel arms for
mounted devices, as well as other accessories,
such as gas cylinders, vaporizer units, CLIC ab-
sorbers and CLIC adapters.
WARNING
Reduced weight carrying capacity and tipping
stability
The front castors on the Primus Infinity
Empowered ceiling device are not mechani-
cally designed to take heavy loads. For this
reason, the front castors are not suitable for
transportation purposes as they are intended
solely as a maneuvering aid when connecting
the ceiling supply unit. Once a wall or ceiling
device is removed from the ceiling supply unit
or wall mount it will no longer fulfill the me-
chanical requirements of ISO 80601-2-13 and
IEC 60601-1.
To position the Primus Infinity Empowered
ceiling device, tilt it back and move it on its
rear castors.
