Dräger Primus Infinity Empowered - Symbols

Instructions for use Primus Infinity Empowered SW 4.5n 33
Overview
Symbols
Symbol Explanation
Manufacturer
Date of manufacture
Suppress alarm tone for 2 minutes,
change priority of technical alarms
or acknowledge them
Call up standard screen
Call up basic screens in succession
Standby/operation switch
Non-rebreathing system at the ex-
ternal fresh-gas outlet
Pulse rate
Fresh gas flowing
Action in progress
Upper and lower alarm limits
Upper alarm limit only
Lower alarm limit only
Alarm tone suppressed for
2 minutes
Alarm monitoring inactive
Alarm monitoring temporarily inac-
tive
Apnea alarm disabled
Upper and lower alarm limit disa-
bled
XXXX
Upper alarm limit disabled
Lower alarm limit disabled
Alarm limit or measuring function
disabled
4-digit access code entered
More than 3 alarms active
Protection class type BF (body
floating)
ESD warning symbol, observe the
warning statement, see "Informa-
tion on electromagnetic compatibil-
ity" on page 10
Interference
FCC (Federal Communications
Commission) symbol
Connection for potential equaliza-
tion cable
Light
Caution! Consult accompanying
documentation!
Caution! (safety symbol)
Consult instructions for use
Warning! Strictly follow these in-
structions for use
Exit menu,
return to preceding menu
Remaining battery capacity
(uninterruptible power supply UPS)
Battery supply
Symbol Explanation
more
