Ducati Monster 796 - Page 129

Wiring diagram
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_6_1A.24.1.html[11/12/2015 18:40:18]
24 Table G Horn connector
25 Table H/Table E Regulator/alternator connector
26
Table H/Table E Regulator/main wiring harness connector
27
Table H/Table E Voltage regulator
28
Table J/Table F Potentiometer connector
29
Table K Horizontal cylinder coil connector
30
Table L Horizontal cylinder exhaust lambda sensor
31
Table L Horizontal exhaust lambda sensor connector
32
Table L Vertical exhaust lambda sensor connector
33
Table L Fuel tank flange connector
34
Table L Vertical cylinder exhaust lambda sensor
35
Table M Data acquisition (DDA) connector
36
Table N Rear wiring harness connector
37
Table N Number plate light connector
38
Table N Rear left turn signal connector
39
Table N Right rear turn signal connector
40
Table N Rear brake light connector
41
Table O Fuse box
42
Table O Throttle pressure/vacuum sensor
43
Table P Contactor/battery positive terminal cable
44
Table P Injection/lights relay
45
Table P ECU connector
46
Table P Vertical cylinder coil connector
47
Table P Starter contactor connector
48
Table Q/Table R Vertical cylinder temperature sensor
49
Table R/Table Q Pickup connector
50
Table R Pick-up sensor
51
Table P Solenoid/starter motor cable
52
Table S Oil pressure switch connector
53
Table T Neutral cable switch connection
54
Table U Rear brake light sensor connector
55
Table U Rear speed sensor connector
56
Table U Rear speed sensor (see Sect. 7 - 6, Flexible wiring/hoses
positioning)
57
Table E Stepper motor
58
Table M Exhaust valve motor connector
59
Table V Front speed sensor connector (only for 796 ABS)
60
Table V Front speed sensor cable (see Sect. 7 - 6,Flexible wiring/hoses
positioning) (only for 796 ABS)
61
Table M ABS diagnosis (only for 796 ABS)
62
Table M ABS diagnosis (only for 796 ABS)
63
Table P ABS control unit connector (only for 796 ABS)
64
Table P Voltage regulator fuse and ABS fuses (only for 796 ABS)
65
Table P ABS positive terminal (only for 796 ABS)
66
Table P ABS negative terminal (only for 796 ABS)
