Air intake
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_8_7.60.1.html[11/12/2015 18:40:41]
Detach the tabs (B) and release the drain hose (12) from the cover (A) on the generator cover (Sect. 9 - 8, Removal of
the generator cover).
Disconnect the cables (C) of horizontal cylinder coil (D) and the vertical cylinder coil (E) from the respective spark plugs.
Disconnect the coil connectors (F) from main wiring harness (Sect. 6 - 1,
Routing of wiring on frame).
Loosen the clamps (G) of the couplings (H).
