Clutch assembly: clutch cover
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_9_6B.73.1.html[11/12/2015 18:40:49]
Refitting the clutch cover
Clean and degrease mating surfaces on the clutch-side crankcase cover and crankcase and ensure that locating bush (13)
and the O-ring (12), located in correspondence with the oil way, are installed in the crankcase.
Apply a uniform continuous bead of DUCATI liquid gasket (B) onto crankcase mating surfaces, working around all the
holes.
Fit the cover assembly (1) to the crankcase half and insert the retaining screws. Tighten the screws (2), (3) and (5) to a
torque of 10 Nm (Min. 9 Nm - Max. 11 Nm) (Sect. 3 - 3,
Engine torque settings) in a crosswise pattern.
Operations Section reference
Connect the oil pressure sensor 6 - 5, Checking the indicating devices
Top up the engine oil 4 - 3,
Changing the engine oil and
filter cartridge
