Crankcase assembly: external components
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_9_9A.78.1.html[11/12/2015 18:40:52]
Fit the exhaust plug (9) with the corresponding gasket (29) and tighten it to a torque of 20 Nm (Min. 18 Nm - Max. 22
Nm)
(Sect. 3 - 3,
Engine torque settings), after applying the recommended threadlocker.
Refit the neutral switch (19) and the corresponding seal (20) and tighten it to a torque of 10 Nm (Min. 9 Nm - Max. 11
Nm)
(Sect. 3 - 3,
Engine torque settings).
Apply threadlocker on the plug (27), fit it with the corresponding seal (28) and tighten the plug to a torque of 25 Nm
(Min. 22 Nm - Max. 28 Nm) (Sect. 3 - 3, Engine torque settings).
Refit the mesh filter (18) with its seal as described in Section 4 - 3, Changing the engine oil and filter cartridge.
