5/7
3. Mode
35320
35320
Maintenance
Output Check (Processor) [SM]
Description for each specification
For the specifications other than [F] specification, this section only gives description that differs from that for [F] specification. See below
for the description for each specification.
!
!!
! 1 [SM]
!
!!
! 2 [SM]
!
!!
! 3 [SM]
Reference
☞Output Check (Processor) [N] ☞Output Check (Processor) [J] ☞Output Check (Processor) [F]
No. Display Status
1 Drive Motor + Drive Cooling Fan Press Execute to start, and Cancel to stop.
2 CD Heater Press Execute to start, and Cancel to stop.
3 BF Heater Press Execute to start, and Cancel to stop.
4 STB Heater Press Execute to start, and Cancel to stop.
5 CD Cooling Water Solenoid Valve Press Execute to start, and Cancel to stop.
6 BF Cooling Water Solenoid Valve Press Execute to start, and Cancel to stop.
7 STB Cooling Water Solenoid Valve Press Execute to start, and Cancel to stop.
8 Tank Cooling Fan Press Execute to start, and Cancel to stop.
9 Exhaust Fan Press Execute to start, and Cancel to stop.
10 Processor Condition Lamp (Green) Press Execute to turn on, and Cancel to turn off.
11 Processor Condition Lamp (Red) Press Execute to turn on, and Cancel to turn off.
12 Signal Lamp Press Execute to turn on, and Cancel to turn off.
13 Control Strip Advance Motor • Execute: Control Strip Advance Motor starts.
• Cancel: Control Strip Advance Motor does not stop.
No. Display Status
1 CD-A Replenisher Pump Press Execute to operate once.
2 CD-B Replenisher Pump Press Execute to operate once.
3 CD-C Replenisher Pump Press Execute to operate once.
4 CD-W Water Supply Pump Press Execute to operate once.
5 BF-A Replenisher Pump Press Execute to operate once.
6 BF-B Replenisher Pump Press Execute to operate once.
7 BF-W Water Supply Pump Press Execute to start, and Cancel to stop.
No. Display Status
1 STB Replenisher Pump Press Execute to operate once.
2 STB 1-W Refilling Water Pump Press Execute to start, and Cancel to stop.
3 STB 2-W Refilling Water Pump
4 STB 3-W Refilling Water Pump
5 STB 4-W Water Supply Pump
6Cleaning Pump
7 Circulation Pump Stand-by Press Execute to start, and Cancel to stop.
