4. Troubleshooting
46100
27/33
46100
Error message: Printer 2
No. 06196
Paper did not rewind. Paper Magazine A2
Error message release
YES
Condition
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 Even when a specified length of paper is rewound after the paper rewinding has started, the paper loading sensor
does not turn light.
00002 Even when a specified length of paper is rewound after the paper loading sensor has turned light, paper end
sensor A2 does not turn LIGHT.
1 Check that the paper is correctly inserted into the paper magazine.
2 Clean the advance roller.
3 Check that the paper loading sensor and the paper end sensor are not soiled.
Advance failure Manual No.
Paper magazine motor A2
☞63051
Paper supply motor A2 ☞63055
Paper supply motor A ☞63060
Printer I/O PCB 2
☞66030
Quad magazine PCB ☞66055
Printer control PCB ☞66000
Detection failure (paper end sensor) Manual No.
Paper end sensor A2 ☞63051
Quad magazine PCB ☞66055
Printer control PCB
☞66000
Detection failure (paper loading sensor) Manual No.
Paper loading sensor
☞66030
Printer I/O PCB 2
☞66030
Printer control PCB ☞66000
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 −−
