Frontier LP7500 - No. 06113 Paper DID Not Rewind. Paper Magazine C

6/33
4. Troubleshooting
46100
46100
Error message: Printer 2
No. 06113
Paper did not rewind. Paper Magazine C
Error message release
YES
Condition
Check Point
Diagnosis
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 Even when a specified length of paper is rewound after the paper rewinding has started, the paper loading sensor
does not turn light.
00002 Even when a specified length of paper is rewound after the paper loading sensor has turned light, paper end
sensor C does not turn LIGHT.
1 Check that the paper is correctly inserted into the paper magazine.
2 Clean the advance roller.
3 Check that the paper loading sensor and the paper end sensor are not soiled.
Advance failure Manual No.
Paper magazine motor C
☞63051
Paper supply motor B/C ☞63060
Printer I/O PCB 2 ☞66030
Printer I/O PCB 1
☞66020
Printer control PCB ☞66000
Detection failure (paper end sensor) Manual No.
Paper end sensor C
☞63051
Printer I/O PCB 3 ☞66040
Printer control PCB ☞66000
Detection failure (paper loading sensor) Manual No.
Paper loading sensor ☞66030
Printer I/O PCB 2
☞66030
Printer control PCB
☞66000
