8. Appendix
80110
80110
Periodically replaced parts
Upper guide
Bearing (upper guide No.2)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A032741 Three years 4
A032742 4
Upper guide
Gear (upper guide No. 2)
A050698 1
Upper guide
Bearing (upper guides No.3 to 6)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A032741 Three years 4 each
A032742 4 each
Upper guide
Gear (upper guides No. 3 to 6)
A050698 1 each
Upper guide
Turn roller (squeegee roller)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A087422 Three years • [F]: 0
[N]: 1
[SM][J]: 1
A087421 • [F]: 0
[N]: 1
[SM][J]: 1
A087419 • [F]: 1
[N]: 0
[SM][J]: 0
Upper guide
Bearing (squeezee roller)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A032741 Three years 4
A032742 4
Upper guide
Gear (squeegee roller)
A050698 1
Processing rack section
Gear
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A050696 Three years 6
A050695 6
Processing rack section
(PP7500/PP7600/QSS-
3701/3702)
Roller holder
A051198 • [F]: 3
[[F][N][SM][J]: 6
A084428 • [F]: 3
[[F][N][SM][J]: 0
Processing rack section (PP-
7900/QSS-3703)
Roller holder
A051198 • [F]: 4
[[F][N][SM][J]: 6
A084428 • [F]: 2
[[F][N][SM][J]: 0
Replenisher pump
Poppet valve (fluoro rubber)
Check its damage. If it is damaged,
replace it with a new one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
I091040 Three years • [F]: 2
• [SM]: 8
• CP-47L, VPII, QLII,
ACPII: 2
Replenisher pump
Poppet valve (EPDM)
Check its damage. If it is damaged,
replace it with a new one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
I091003 Three years • [F]: 4
• [N]: 6
• [SM]: 2
• [J]:6
• CP-47L, VPII, QLII,
ACPII: 4
Parts or checking items Description for maintenance Part No. Timing/Standard
replacement
timing
Quantity
