Periodically replaced parts
Processor section (common to the PP7700/QSS-3704[N] [SM] [F])
Processor section (QSS-3701/3702[N])
Parts or checking items Description for maintenance Part No. Timing/Standard
replacement
timing
Quantity
Replenisher pump
Poppet valve (fluoro rubber)
Check its damage. If it is damaged,
replace it with a new one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
I091040 Three years • [F]: 2
• [SM]: 8
• CP-47L, VPII, QLII,
ACPII: 2
• ACPII: 4
Replenisher pump
Poppet valve (EPDM)
Check its damage. If it is damaged,
replace it with a new one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
I091003 Three years • [F]: 4
• [N]: 6
• [SM]: 2
• [J]:6
• CP-47L, VPII, QLII,
ACPII: 4
Parts or checking items Description for maintenance Part No. Timing/Standard
replacement
timing
Quantity
Upper guide
Turn roller (EPDM) (No. 3
upper guide)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A087423 Three years 3
Upper guide
Bearing (upper guide No.3)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A032741 Three years 4
A032742 4
Upper guide
Gear (upper guide No. 3)
A050698 1
Upper guide
Bearing (upper guides No.5 to 8)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A032741 Three years 4 each
A032742 4 each
Upper guide
Gear (upper guides No. 5 to 8)
A050698 1 each
Upper guide
Turn roller (squeegee roller)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A083186 Three years 1
A087421 1
Upper guide
Bearing (squeezee roller)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A032741 Three years 4
A032742 4
Upper guide
Gear (squeegee roller)
A050698 1
Processing rack section
Gear
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A050696 Three years 8
A050695 8
Processing rack section
Roller holder
A051198 8
