Position of electrical parts (printer section)
1/2
6. Electrical parts
63050
63050
Printer section (positions of electrical parts)
!
!!
! Position (front face)
Printer main body (front face)
No. Name Symbol Remarks
1 Interlock Switch (Printer Door 1)
*2
LS2
*1
2 Interlock Switch (Printer Door 2)
*2
LS3
3 Printer Door 3 Sensor
*2
LS4
4 Control box cooling fan 2 FAN3 Intake (The fan is always on.)
7
6
5
9
3
1
2
4
10
8
For the triple magazine unit
12
13
14
G085244
11
3
9
10
For the quad magazine unit
G086493
