Frontier LP7500 - No. 06201 Paper DID Not Load. Paper Magazine a

32/33
4. Troubleshooting
46100
46100
Error message: Printer 2
No. 06201
Paper did not load. Paper Magazine A
Error message release
YES
Condition
NOTE
• When the quad magazine unit is installed, this message appears.
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 Even though a specified length of paper is advanced after paper loading started, paper end sensor A does not turn
DARK during setup or printing for mechanical adjustments.
00002 Even when a specified length of paper is advanced after the paper end sensor A has turned DARK, the loading
sensor does not turn dark.
1 Check that the paper is correctly inserted into the paper magazine.
2 Clean the advance roller.
Advance failure Manual No.
Paper magazine motor A
☞63051
Paper supply motor A ☞36060
Printer I/O PCB 2 ☞66030
Quad magazine PCB
☞66055
Printer control PCB ☞66000
Detection failure (paper end sensor) Manual No.
Paper end sensor A
☞63051
Quad magazine PCB ☞66055
Printer control PCB ☞66000
Detection failure (paper loading sensor) Manual No.
Paper loading sensor
☞66030
Printer I/O PCB 2 ☞66030
Printer control PCB
☞66000
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 −−
