4. Troubleshooting
46100
31/33
46100
Error message: Printer 2
No. 06200
Width Change Motor A2 operation error.
Error message release
NO
Condition
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 The width change sensor A2 does not turn DARK even though the paper guide in the paper supply unit A2
started initial operation.
00002 The width change sensor A2 does not turn LIGHT even though the paper guide in the paper supply unit A2
moved to a specified position.
1 Check that the paper supply unit A2 is installed correctly.
Operation failure Manual No.
Width change motor A2 ☞ 63051
Printer I/O PCB 1 ☞66020
Quad magazine PCB
☞66055
Printer control PCB ☞66000
Printer power supply 3 ☞66100
Detection failure Manual No.
Width change sensor A2 ☞63051
Quad magazine PCB ☞66055
Printer control PCB
☞66000
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 −−
